GlowSTX GSA Suspended Linear System

LF Illumination

Product Details

Manufacturer's Product Page


Spec Sheets

GlosSTX Suspended LInear Luminaire System
GlowSTX Accent Spot Surface

Features

  • Lumens (approx): 1 - 500 Per Foot
  • Mounting: Cable, Pendant
  • Shape: 90 Degree , Curved, Custom, Hexagon, Rectangle, Round / Circle, Square
  • Size: 24", 36", 48", 72", 96"
  • Source: LED

Applications

  • Cafeteria
  • Decorative
  • Elevator Lobby
  • Lobby / Reception
  • Open Office

Suspended Linear System

LINEAR SECTION CONSTRUCTION

  • 79” (20) wide x 2.24” (57) pendant system
  • Die-cast, extruded and injection molded components
  • Fixed and adjustable joiners allow for multiple configurations
  • Powder coat finish

LINEAR LED SOURCE

  • 5W LED / 400lm per foot
  • Dense pitch for uniform output

OPTICS

  • Smooth satin white extruded acrylic lens

ACCENT UNIT CONSTRUCTION

  • 1.57” diameter accent light
  • Screws in to linear connector
  • 0° - 95° vertical tilting / 360º horizontal rotation
  • Constant friction
  • Die cast aluminum housing
  • LED optical grade TIR reflector in narrow, medium, wide, and very wide
  • Powder coat finish

ACCENT LED SOURCE

  • CREE 7W LED / 510lm (@ 80CRI min / 3000K)
  • Field replaceable optics available
  • Will accept 1 additional media accessory

ELECTRICAL

  • Integral wiring
  • Integral thermal protection
  • Continuous runs
  • Integral or remote power supply kits

MOUNTING

  • Aircraft cable suspension with grip-lock hardware and power feed options

LABELS

  • Suitable for damp location



Show more
